Home \ Proteins and peptides \ CpG-A DNA (ODN 2216), Human/Mouse
CpG-A DNA (ODN 2216), Human/Mouse-0
Catalog # HC4037-200nmol

CpG-A DNA (ODN 2216), Human/Mouse


Please choose the quantity of items you wish to add to your cart…
Find distributor

ODN 2216 is a prototype of the class of CpG-A oligodeoxynucleotides (ODN), also known as ‘D’-type ODN, and contains a phosphodiester (PO) backbone. It is particularly effective for activating NK cells and inducing IFN-alpha production in plasmacytoid dendritic cell (PDC) precursors.
The vertebrate immune system has evolved innate immune defense pattern recognition receptors (PRRs) that detect unmethylated cytosine-phosphate-guanine (CpG) motifs within bacterial DNA. Cellular activation by CpG motifs occurs via the Toll signal pathway. The Toll-like receptor-9 (TLR9, CD289) appears to be a major component of the CpG-DNA receptor, acting by direct binding to CpG-DNA, which triggers the induction of cell signaling pathways including the mitogen activated protein kinase (MAPKs) and NFκB, leading to stimulation of various cells of the immune system. The human TLR9 is expressed in B cells and PDC. Mice also express TLR9 in the myeloid compartment. Optimal sequences for activating TLR9 vary among species. Synthetic ODN contain CpG-DNA motifs mimicking the immunostimulatory effects of bacterial DNA and can, therefore, be used as immunoprotective agents, vaccine adjuvants and anti-allergic agents. CpG ODN also affects immune tolerance and autoimmunity. Different classes of CpG ODN are characterized each with distinct effects on the immune response: CpG-A (‘D’-type), CpG-B (‘K’-type), and CpG-C.
CpG-A ODN are characterized by poly-G motifs with phosphorotioate (PS) linkages at the 5’ and 3’ ends (facilitating cellular uptake) and a PO palindromic CpG-containing sequence in the ODN center. CpG-A ODN induces large amounts of IFN-alpha in PDC (unlike CpG-B), resulting in strong activation and IFN-gamma production in NK cells and gamma-delta T cells, but fails to activate B cells. Human monocytes exposed to the cytokine milieu elicited by CpG-A can differentiate into dendritic cells.
The prototype sequence of a CpG-A is the 20-mer ODN 2216 that mimics viral infection of PDC and is able to modulate the immune response in both human and mice. It has the following sequence: 5’-ggGGGACGATCGTCgggggG-3’. Lowercase letters represent PS linkage, uppercase letters represent PO linkage 3’ of the base and bold letters represent CpG dinucleotides.

Functional studies

Application Notes
CpG-A DNA can be used in biological assays in vitro to activate cells. Furthermore, CpG-A DNA can be used as an immune modulating agent.

For in vitro stimulation, 0.05 to 3 μM can be used. It is recommended that users test the reagent and determine their own optimal concentrations.

Product type
LPS and ligands
200 nmol
Approximately 200 nmol lyophilized, purified 20-mer CpG ODN. The exact amount is indicated on the label. Endotoxin levels are undetectable. Reconstitute the vial by pipetting distilled or deionized water, volume depending on the concentration to be used.
Storage and stability
Lyophilized product should be stored at 4 °C. Store stock solution in aliquots at -20 °C. Repeated freeze and thaw cycles will cause loss of activity. Under recommended storage conditions, product is stable for one year.
For research use only. Not for use in or on humans or animals or for diagnostics. It is the responsibility of the user to comply with all local/state and Federal rules in the use of this product. Hycult Biotech is not responsible for any patent infringements that might result with the use of or derivation of this product.
